*unless specified otherwise
Tightening loose bolts and screws should not be limited to quarterly service, however.
Any time you come across a loose bolt or screw, it should be corrected immediately.
The following item must also be performed quarterly:
o Oil all chains, if necessary.
Note
Oil all chains with very small quantities of SW10 motor oil only if judged necessary. Don't forget
that any excess oil will only drip into undesired place,s causing headaches for cleaning.
Annual (100,000 Frames) Maintenance Schedule
An annual inspection of the pinspotter is best done by a qualified mechanic who has the
experience to determine the wear of parts and their need for replacement. The oil in all
gearboxes must also be checked and added if required (use Kluber Oil 715-022-505). Apply
LOTO procedure where required.
5 Year (500,000 Frames) Maintenance Schedule
Apply LOTO procedure where required. Replace the oil in the gearbox(es). Remove the
motor/gearbox assembly from the pinspotter. Separate the motor from the gearbox and
remove the mounting bracket from the gearbox side opposite the shaft. Loosen and remove
the (oil) plug. Rotate the gearbox to allow the oil to drain from the gearbox. Refill gearbox
with 2.5oz (75ml) of Kluber Oil (715-022-505). Apply thread sealant to the oil plug and
reinstall into the gearbox, tighten securely. Install mounting bracket and motor to gearbox,
then install assembly to pinspotter.
For ball accelerator, remove assembly from the mounting bracket and then separate gearbox
from motor. Follow instructions above to change oil and then reinstall.
