Queclink CV100LG - Page 53

CV100LG User Manual
QSZCAMCV100LGUM0304 49
Dedicated Mobile App
QuCam with features for free
Interface
Slot
USB Type-C, TF Slot, Nano SIM Slot
Output
Open drain, software-defined feature
Connector Type
4-pin connector
Multi-functional
Button
SOS Alarm, Wi-Fi switch, Panic alarm
Indicators
4 single-color LED indicators named CELL, GPS,
REC, PWR
Reboot button
Press the reset button by ejection pin to reboot
the product
General
Dimensions
127.77mm(L) x 53.93mm(W) x 106.69mm(H)
Weight
270g
Backup Battery
Rechargeable 470mAh Li-polymer
Power Input
External power supply, voltage range 8V to 32V
DC, 2Amp fuse protection for both ACC and
battery lines
Mount
3M adhesive tape, windshield glass installation
IMU Sensor
3 axis accelerometer + 3 axis gyroscope
Queclink
Confidential
