CV100LG User Manual
QSZCAMCV100LGUM0304 2
1. Introduction
CV100LG is a compact video telematics dash camera designed for a wide variety of vehicle tracking
and video monitoring applications.
It’s set with dual-lens imaging system to capture real-time high-definition video clips and record
the traffic status, driver’s behavior to track exactly what happened before, during and after an
incident by recording driving data like view of road, audio, speed, GNSS location, acceleration,
braking, crashing, etc.
Its built-in GNSS receiver has excellent sensitivity, making the positioning fast and accurate and
events such as such as an impact and bump while parking can be detected and recorded with the
help of high-performance inertial sensor.
The camera supports WCDMA and LTE CAT4 on multiple bands ensuring it can offer a reliable data
channel so the vehicle can be tracked in real time accurately and the videos can be successfully
uploaded to the back-end server for analysis.
There are more features on it such as extended working time of battery due to the sophisticated
power management algorithm, SOS with audible driver feedback via speaker, excellent cooling
performance by cooling fin with thermal conductive adhesive etc.
It is for sure a great video telematics solution for tracking safety and efficiency.
Report Sever Media ServerBase Station
4G LTE CAT4
3G / 2G
GNSS
Positioning
@Track & Video/Audio
FTP / HTTP / RTMP /QMS
Bluetooth
Panic Button
Wi-Fi
Hotspot Sharing
Dash Cam
1.1. Reference
Table 1. Reference
Document name
Remark
CV100LG @Track Air Interface Firmware Update Protocol
The air protocol interface
between CV100LG and
backend server.
CV100LG @Track Air Interface Protocol
Queclink
Confidential
