26 Jive Up
Rev.2.0
6.0 Seating
6.1 Seat cushions
Seat cushions supplied by Sunrise Medical will have
Velcro® strips that correspond to patches on the seat.
WARNING!
• You must ensure the strips are aligned prior to using
the wheelchair.
• Other cushions used should also have Velcro® strips
in a similar position to ensure the cushion does not
slip off the seat.
NOTE: The seat cushions, supplied by Sunrise Medical
all have removable covers.
6.2 Changing seat depth on the Jive Up / QM-710
Stand Up seat
• Loosen the arm pad width adjustment screws, using a
5.0 mm spanner.
• Repeat for the other side.
• Slide the inner seat frame to the desired position.
• Tighten all screws, (Fig.6.1).
WARNING!
Sunrise Medical strongly recommend that you contact
your approved Sunrise medical servicing agent to carry
out this task.
Fig.6.1
A
6.3 Changing seat height
There are four adjustable seat posts, one at each corner
of the drive base, (Fig.6.2).
The posts are held in place by bolts inserted through
adjustment holes.
To adjust the seat height:
• Remove the bolts from the posts using two 13 mm
spanners.
• Move the posts to the desired position.
• Replace the bolts into the new holes in the posts.
• Tighten the bolts.
DANGER!
• Sunrise Medical strongly recommend that you contact
your approved Sunrise medical servicing agent to
carry out this task.
• If any bolts are removed from the seat frame or seat
posts it is possible that unexpected movement of the
assembly may occur. This could result in serious injury.
• The seating system must never be adjusted beyond
safe limits. Always consult your approves Sunrise
Medical dealer/service agent.
Fig.6.2
6.4 Removable seat covers
The seat covers are all fully removable using zips or
Velcro
®.
Once brackets are removed seat covers can
be removed. The zip for the backrest is located on the
under side of the cushion.
6.5 JAY backrests
The standard backrest assembly will allow the fitting of a
JAY backrest, which is available as an optional extra.
