Cardiac Stress Treadmills Service Manual Specifications B-1
B
Specifications
Cardiac Stress Treadmills Specifications
The following specifications apply to the Cardiac Stress treadmills except
where noted.
Performance
Maximum Rated Load
500 lb (227.3 kg) (with restrictions -- see Speed/
Weight graph on next page)
Belt Speed Range
(Continuously Adjustable)
0.8 to 9.6 mph (1.3 to 15.4 km/h) +
0.2 mph
Grade Range 0 to 25% +
0.5%
Physical
Weight
ST/TM55: 352 lb (160 kg)
ST/TM65: 375 lb (170 kg)
Nominal Walking Area
ST/TM55: 20 in. x 55 in. (51 cm x 140 cm)
ST/TM65: 20 in. x 65 in. (51 cm x 165 cm)
Treadmill Area
ST/TM55: 29.9 in. x 80.2 in. (76 cm x 204 cm)
ST/TM65: 29.9 in. x 90.2 in. (76 cm x 229 cm)
Walking Surface Height 7.0 in. (18 cm) from floor
Handrail Height 47.2 in. (120 cm) from floor
Environmental
Temperature
Operating: 50 to 104°F (10 to 40° C)
Storage: -40 to 158°F (-40 to 70°C)
Humidity (non-condensing)
Operating: 15 to 95% relative
Storage: 5 to 95% relative
