Cardiac Stress Treadmills Service Manual Part Numbers C-3
Placement of Spare Parts
This list shows the basic numbering for each spare part. The following
drawings show where the part is located.
ITEM
#
Part Number Description
1 033510-001 BELT-WALKING 123" BLOCK DESIGN (55"
TREADMILL)
1 033510-002 BELT-WALKING 143" BLOCK DESIGN (65"
TREADMILL)
2 030205-004 SLIDER BED (55" TREADMILL)
2 030205-005 SLIDER BED (65" TREADMILL)
3 032640-001 RH END CAP CASTING
3 032641-001 LH END CAP CASTING
4 033508-002 REAR PULLEY (ROLLER)
5 014639-001 FOOT, REAR, TREADMILL
6 031516-001 ROLLER GUARD WELDMENT
7 032752-001 PLASTIC EXTRUSION, 55" TREADMILL
7 032752-002 PLASTIC EXTRUSION, 65" TREADMILL
8 032804-004 INSERT, PLASTIC EXTRUSION, BLUE
9 033507-003 DRIVE ROLLER ASSY
10 032387-001 POLY-V DRIVE BELT
11 032784-001 ASSY, ROTARY TENSIONER, PULLEY, AND ARM
12 031194-002 BUMPER, GRAY
13 037083-001 ASSY, CONFIG PLATE, LOW VOLTAGE
13 037083-002 ASSY, CONFIG PLATE, LOW VOLTAGE, E-STOP
13 037083-003 ASSY, CONFIG PLATE, HIGH VOLTAGE
13 037083-004 ASSY, CONFIG PLATE, HIGH VOLTAGE, E-STOP
14 042027-001 CHOKE, PFC (for CE marked units ONLY)
15 033316-002 MOTOR ASSEMBLY, GRADE
16 032798-001 MODIFIED RACK GEAR
17 033171-002 ASSY, GRADE POT
18 042153-001 SPARE, AC DRIVE MODULE
19 037098-001 DRIVE MOTOR, AC VARIABLE
20 033167-001 HARNESS ASSY, BUS RECOVERY
21 032706-001 TRANSFORMER, VARIALBLE AC
22 032780-003 PCBA, DIGITAL INTERFACE
23 032446-001 FLYWHEEL ASSY
