3.1.4 The Real-time Monitoring
Whilst in the WEB interface, select the focus window within the live window. The focus
window has a light blue border.
From the left channel column select channel, as shown in the following interface.
Channel Choices
Click on 2 areas in upper right corner and you can choose to open / close the channel
of the main stream or secondary stream. Above the live video window the current
DVR's IP and rate information is shown (please see image below).
Stream information
Lower left corner shows the current video channel name.
Upper right corner shows the current video time information.
Click “ ”(Lower left corner of the display window)to switch between
single screen and multi-screen.
Lower right corner of the display window will display the function keys, as the following
interface (next page).
