RACOM RipEX - CE 25 Khz

Tab. 4.10: CE 25 kHz
CE 25 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-5-6-8-111-115-1182CPFSK0.757.81
-7-8-10-110-114-1172CPFSK1.0010.42
-7-9-9-107-112-1154CPFSK0.7515.63
-9-11-11-104-110-1134CPFSK1.0020.83
-5-6-6-107-112-114DPSK0.7515.62
-7-8-8-106-111-113DPSK1.0020.83
-3-4-4-106-110-113π/4-DQPSK0.7531.25
-5-6-6-104-108-111π/4-DQPSK1.0041.66
-8-8-8-98-103-106D8PSK0.7546.87
-9.5-10-10-95-101-104D8PSK1.0062.49
-5-6-6-95-101-10416DEQAM0.7562.49
-7-8-8-93-99-10216DEQAM1.0083.32
CE 25 kHz Tx
26 dB BandwidthOBW 99% [kHz]
Classification
EmissionModulationkbps
19.613.813K8F1DBN2CPFSK10.42
18.114.214K2F1DDN4CPFSK20.83
27.123.524K0G1DBNDPSK20.83
27.223.924K0G1DDNπ/4-DQPSK41.67
26.923.524K0G1DEND8PSK62.49
27.323.924K0D1DEN16DEQAM83.32
