RACOM RipEX - Narrow 25 Khz

FCC 6.25 kHz Tx
26 dB BandwidthOBW 99% [kHz]
Classification
EmissionModulationkbps
5.013.553K60F1D4CPFSK5.21
5.634.895K00G1Dπ/4-DQPSK8.68
5.564.885K00G1DD8PSK13.02
5.634.875K00G1D16DEQAM17.36
Tab. 4.18: Narrow 25 kHz
Narrow 25 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-5-6-8-111-115-1182CPFSK0.757.81
-7-8-10-110-114-1172CPFSK1.0010.42
-7-9-9-107-112-1154CPFSK0.7515.63
-9-11-11-104-110-1134CPFSK1.0020.83
-6-7-7-109-114-116DPSK0.7510.41
-7-8-8-108-113-115DPSK1.0013.89
-8-8-8-107-111-113π/4-DQPSK0.7520.84
-8-8-9-106-110-112π/4-DQPSK1.0027.78
-8-8-9-101-105-108D8PSK0.7531.25
-9-10-10-100-104-107D8PSK1.0041.67
-9-9-11-99-103-10616DEQAM0.7541.67
-9-10-11-95-101-10416DEQAM1.0055.56
Narrow 25 kHz Tx
26 dB BandwidthOBW 99% [kHz]
Classification
EmissionModulationkbps
19.613.813K8F1DBN2CPFSK10.42
18.114.214K2F1DDN4CPFSK20.83
18.215.915K9G1DBNDPSK13.89
18.215.915K9G1DDNπ/4-DQPSK27.78
18.015.915K9G1DEND8PSK41.67
18.115.915K9D1DEN16DEQAM55.56
Note
All the Sensitivities above are guaranteed ones, i.e. every single unit has got typically
even better values for 0–4 dB.
1.
2. BER (Bit Error Rate) is calculated from PER (Packet Error Rate) when packet size was
60 Bytes.
67© RACOM s.r.o. – RipEX Radio modem & Router
