Tab. 4.13: FCC 50 kHz
FCC 50 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-15-16-16-108-112-1152CPFSK0.7515.62
-15-16-17-107-111-1132CPFSK1.0020.83
-15-21-21-103-107-1104CPFSK0.7531.25
-16-21-21-102-106-1094CPFSK1.0041.67
-15-15-15-105-109-112DPSK0.7526.04
-15-15-15-104-108-110DPSK1.0034.72
-17-21-21-100-104-107π/4-DQPSK0.7552.08
-17-21-21-99-103-106π/4-DQPSK1.0069.44
-15-21-20-96-99-102D8PSK0.7578.12
-16-21-20-95-98-101D8PSK1.00104.17
-14-17-17-95-98-10116DEQAM0.75104.17
-15-1717-94-97-10016DEQAM1.00138.89
FCC 50 kHz Tx
26 dB BandwidthOBW 99% [kHz]
Classification
EmissionModulationkbps
37.028.028K0F1D4CPFSK41.67
45.539.340K0G1DDPSK34.72
45.639.240K0G1Dπ/4-DQPSK69.44
44.839.540K0G1DD8PSK104.17
45.139.140K0D1D16DEQAM138.89
Tab. 4.14: FCC 25 kHz
FCC 25 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-0-1-3-108-113-1164CPFSK0.7515.63
-1-2-5-105-111-1144CPFSK1.0020.83
-1-2-4-107-111-114π/4-DQPSK0.7526.04
-2-4-6-105-109-112π/4-DQPSK1.0034.72
-5-7-9-99-105-108D8PSK0.7539.06
-7-9-11-96-103-106D8PSK1.0052.08
-8-9-12-96-103-10616DEQAM0.7552.08
-10-12-14-94-101-10416DEQAM1.0069.44
