RACOM RipEX - FCC 12.5 Khz; FCC 6.25 Khz

Tab. 4.16: FCC 12.5 kHz
FCC 12.5 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-4-5-5-108-114-1174CPFSK0.757.81
-6-7-7-105-112-1154CPFSK1.0010.42
-2-2-2-109-113-115π/4-DQPSK0.7513.02
-3-4-4-106-111-114π/4-DQPSK1.0017.36
-5-6-6-101-106-109D8PSK0.7519.53
-7-8-8-98-104-107D8PSK1.0026.04
-2-3-3-99-104-10716DEQAM0.7526.04
-4-5-5-96-102-10516DEQAM1.0034.72
FCC 12.5 kHz Tx
26 dB BandwidthOBW 99% [kHz]
Classification
EmissionModulationkbps
11.38.68K60F1D4CPFSK10.42
11.39.8310K0G1Dπ/4-DQPSK17.36
11.29.8710K0G1DD8PSK26.04
11.39.8810K0G1D16DEQAM34.72
Tab. 4.17: FCC 6.25 kHz
FCC 6.25 kHz Rx
Blocking or
desensitization [dBm]Sensitivity [dBm]Classification
±10 MHz±5 MHz±1 MHzBER 10
-6
BER 10
-3
BER 10
-2
ModulationFECkbps
-2-2-2-112-117-1204CPFSK0.753.91
-3-4-4-109-115-1184CPFSK1.005.21
-2-3-3-113-116-118π/4-DQPSK0.756.51
-4-5-5-111-114-117π/4-DQPSK1.008.68
-2-2-2-105-110-112D8PSK0.759.77
-3-4-4-102-107-110D8PSK1.0013.02
-2-3-3-103-107-11016DEQAM0.7513.02
-4-5-5-100-105-10816DEQAM1.0017.36
