RadComm RC2PLUS User Manual

RC2
PLUS
USER MANUAL REV 9
RC2 PLUS User Manual
150
-
85
-
002 Revision 9.0
–
August 21,2020
Page
13
the joystick UP/DOWN highlights the setting to change.
Using the joysticks RIGHT/LEFT on the selected options changes the setting.
Once the changes are made HOLD DOWN to save.
The configuration screen displays the following:
4.2.1 SENSITIVITY
There are 3 alarm thresholds, which correspond to the level of sensitivity, normally
LOW, MED and HIGH. Low level threshold equals to 12 Standard Deviation of
ambient background (12
√
𝐵𝐺
)+ambient background.
LOW
𝐵𝐺
+
12
√
𝐵
𝐺
MED
𝐵𝐺
+
8
√
𝐵𝐺
HIGH
𝐵𝐺
+
4
√
𝐵𝐺

RadComm RC2PLUS Specifications

Battery

battery life	20 hours
battery recharge time fast charge	2.5 hrs
battery recharge time via PC USB	6 hrs min.

Detector Specifications

PVT size height	101.6 mm
PVT size length	76.2 mm
PVT size width	50.8 mm
Geiger-Mueller tube size diameter	12 mm
Geiger-Mueller tube size length	45 mm

Response and Sensitivity

energy range	15 KeV – 2.0 MeV
sensitivity	8 cps/uCi at 1M with CS137
gamma histogram channels	256
gamma histogram channel capacity	16 bits
accumulate dose	5.5 mSv

Weight and Dimensions

detector case height	18 cm
detector case length	23 cm
detector case width	10 cm
