RadComm RC2PLUS User Manual

RC2
PLUS
USER MANUAL REV 9
RC2 PLUS User Manual
150
-
85
-
002 Revision 9.0
–
August 21,2020
Page
18
5.2.2 RC2
PLUS
ADVANCED STATUS BAR
5.2.2.1 SCANNING
The RC2
PLUS
is in normal operation. Ready for search and find.
5.2.2.2 CALIBRATION REQUIRED
This message is displayed when the RC2
PLUS
needs to be recalibrated. This message
will appear after one year or LED test fails.
5.2.2.3 ALARM: ROI1 or 2/3/4 or Total!
This message is displayed when the RC2
PLUS
is alarming. The unit warns the user
with the audio, visual and tactile notifications. The RC2
PLUS
will display the ROI# or
Total window where the current reading value is above its alarm threshold.
5.2.2.4 HIGH DOSE RATE. MOVE AWAY!
When the dose rate reading is higher than 10µSv/h this message is displayed.
5.2.2.5 SYSTEM IS OUT OF RANGE!
This message is displayed when the dose rate is higher than 50mSv/h. The unit has
overloaded its scanning capacity.
5.2.2.6 DOSE RATE EXCEEDS THRSH!
This is an alarm message displayed when the dose rate value exceeds its threshold
setting. The unit warns the user with the audio, visual and tactile notifications. This
setting is configurable through the Dose Setup in the Configuration screen.
5.2.2.7 DOSE MEMORY IS FULL!
This message is displayed when the memory for Dose
data is full.
5.3 HISTOGRAM
The Histogram function in the RC2
PLUS
allows the user to
accumulate the histogram of a radioactive source.
The accumulation begins the moment the user enters the
Histogram mode.
The Histogram also includes 4 ROI windows highlighted
in different colors.

RadComm RC2PLUS Specifications

Battery

battery life	20 hours
battery recharge time fast charge	2.5 hrs
battery recharge time via PC USB	6 hrs min.

Detector Specifications

PVT size height	101.6 mm
PVT size length	76.2 mm
PVT size width	50.8 mm
Geiger-Mueller tube size diameter	12 mm
Geiger-Mueller tube size length	45 mm

Response and Sensitivity

energy range	15 KeV – 2.0 MeV
sensitivity	8 cps/uCi at 1M with CS137
gamma histogram channels	256
gamma histogram channel capacity	16 bits
accumulate dose	5.5 mSv

Weight and Dimensions

detector case height	18 cm
detector case length	23 cm
detector case width	10 cm
