RadComm RC2PLUS User Manual

RC2
PLUS
USER MANUAL REV 9
RC2 PLUS User Manual
150
-
85
-
002 Revision 9.0
–
August 21,2020
Page
30
8.0 SPECIFICATIONS
Mechanical
Detector Case: 7" H(18cm) x 9" L(23cm) x 4"
W(10cm)
System weight:
Micro USB Connector for Internal Battery
Charging and data transfer
Thru-hole for Audio Alarm
Electronics
Integral PMT with EM Shielding
Audio Alarm with Vibration
Stable Low Noise, High Voltage Power Supply
Internal Rechargeable Li Ion Battery with
Charging LED indicator
Battery Life: 20 hours continuous
Battery Recharge Time:
Fast Charge: 2.5 hrs
via PC USB: 6 hrs min.
Software
Menu Driven User Interface
Configurable Data Storage with Backup
Emailing capability (with network connection)
Configurable Data Storage with Backup
Emailing capability (with network connection)
Detector Specifications
PVT: Size 4"(101.6mm) x 3"(76.2mm) x
2"(50.8mm)
Optional Geiger-Mueller tube, size
0.59"(12mm) x 1.9"(45mm)
Response/Sensitivity
Energy Range: 15 KeV – 2.0 MeV
Sensitivity: 8 cps/uCi at 1M with CS137
Gamma histogram: 256 Channels, channel
capacity 16 bits
Accumulate dose up to 5.5mSv, custom
increase
RC2
PLUS
BASIC vs ADVANCED
Feature
Basic
Option
Advanced
Option
Search+Find
 
Total Counts
 
Dose Rate
 
Dose Rate Alarm
 
Histogram

Graph Plotting

ROI Analysis

ROI Alarm
Threshold
Settings

Data storage

Accumulated
Dose


RadComm RC2PLUS Specifications

Battery

battery life	20 hours
battery recharge time fast charge	2.5 hrs
battery recharge time via PC USB	6 hrs min.

Detector Specifications

PVT size height	101.6 mm
PVT size length	76.2 mm
PVT size width	50.8 mm
Geiger-Mueller tube size diameter	12 mm
Geiger-Mueller tube size length	45 mm

Response and Sensitivity

energy range	15 KeV – 2.0 MeV
sensitivity	8 cps/uCi at 1M with CS137
gamma histogram channels	256
gamma histogram channel capacity	16 bits
accumulate dose	5.5 mSv

Weight and Dimensions

detector case height	18 cm
detector case length	23 cm
detector case width	10 cm
