RadComm RC2PLUS User Manual

RC2
PLUS
USER MANUAL REV 9
RC2 PLUS User Manual
150
-
85
-
002 Revision 9.0
–
August 21,2020
Page
17
5.2.1 SEARCH ALARM
The Total and ROIs have % above background thresholds. Each can be set through
the configuration screen.
The Red Line displays the alarm threshold for this total window.
When a radioactive source is in proximity, its counts and graph will increase.
The alarm triggers when the increased counts cross the Red line. In this event the
user is notified with:
 Audio Alarm
 Visual Alarm (RED LED)
 Tactile Alarm (Handle Vibrates)
RED LED Visual Alarm
Introduced source
increases the counts.
Audio Alarm
(( ))
Tactile notification

RadComm RC2PLUS Specifications

Battery

battery life	20 hours
battery recharge time fast charge	2.5 hrs
battery recharge time via PC USB	6 hrs min.

Detector Specifications

PVT size height	101.6 mm
PVT size length	76.2 mm
PVT size width	50.8 mm
Geiger-Mueller tube size diameter	12 mm
Geiger-Mueller tube size length	45 mm

Response and Sensitivity

energy range	15 KeV – 2.0 MeV
sensitivity	8 cps/uCi at 1M with CS137
gamma histogram channels	256
gamma histogram channel capacity	16 bits
accumulate dose	5.5 mSv

Weight and Dimensions

detector case height	18 cm
detector case length	23 cm
detector case width	10 cm
