RadComm RC2PLUS User Manual

RC2
PLUS
USER MANUAL REV 9
RC2 PLUS User Manual
150
-
85
-
002 Revision 9.0
–
August 21,2020
Page
29
The system will not be scanning during this period. The lamp is a maintenance free
LED cluster and is powered by low voltage DC.
Alarm Reset
The audio reset is an illuminated pushbutton located on the front panel. This reset
will reset both the audio and visual alarms. Once the alarms have been reset the
system automatically reactivates the alarm for the next radiation detection.
RC2
PLUS
I/O Connector
The RC2
PLUS
I/O connector is located inside at the end of the communication cable.
The connector is a standard DIN 10 pin connector. It must be firmly plugged into the
bottom right hand side of the RC2
PLUS
portable. All communication signals and
battery charging voltage (12 volts DC) is through this I/O connector.
Latch
There are two latches located on the right of the unit. A padlock can be added to
the bottom latch for security.
Front Door
The front door is weather sealed with an outer hinge on the left side. There is also a
RC2
PLUS
display viewing window to allow viewing of the RC2
PLUS
display without
opening the door.
Audio Alarm
The Audio Alarm is located on the bottom of the Console. The audio will sound if
the RC2
PLUS
Portable detects radiation that exceeds the alarm level settings. The
audio is powered by low voltage DC. The output audio signal level is a continuous
2200 Hz tone with an output of 90 db at approximately 3 ft. The Audio will stay
steady ON until it is reset.
AC Input
There is a 21mm (3/4") conduit hole at the bottom right corner of the cabinet
available for the AC power input. The unit requires 100 230 volts AC /50/60 Hz.

RadComm RC2PLUS Specifications

Battery

battery life	20 hours
battery recharge time fast charge	2.5 hrs
battery recharge time via PC USB	6 hrs min.

Detector Specifications

PVT size height	101.6 mm
PVT size length	76.2 mm
PVT size width	50.8 mm
Geiger-Mueller tube size diameter	12 mm
Geiger-Mueller tube size length	45 mm

Response and Sensitivity

energy range	15 KeV – 2.0 MeV
sensitivity	8 cps/uCi at 1M with CS137
gamma histogram channels	256
gamma histogram channel capacity	16 bits
accumulate dose	5.5 mSv

Weight and Dimensions

detector case height	18 cm
detector case length	23 cm
detector case width	10 cm
