34 Chapter 3
Create an electrodeCreate an electrode
Create an electrodeCreate an electrode
Create an electrode
1. Press 4 Electrode Library, then 1 New electrode.
2. Press ✓ in the Function field and select the function of the
electrode, refer to the table below:
Electrode type Select function
Single pH pH
Combined pH w/wo temp. sensor pH
Single metal/redox mV (i=0)
Combined metal/redox w/wo temp. sensor mV (i=0)
Single ISE mV (i=0)
Combined ISE w/o temp. sensor mV (i=0)
Reference single Reference
Temperature sensor T°C
Ground metal Ground
Double metal mV (i > 0)
3. Press ✓ in the ID field.
4. Select Other in the From field.
The option
From = Catalogue
allows you to create an
electrode from a list of Radiometer Analytical electrodes.
5. Enter the identification (ID) of the electrode, (up to 16 characters).
6. Press 1 twice.
