Table 3: D8128C OctoPOPIT Address Switch Settings
NOTES:
a. Dipswitch 4 is not used for setting addresses.
b. A D8128C OctoPOPIT cannot be installed at the end of
either ZONEX (for points 121-127 or points 241-247). Use
a D8125 POPEX module and D9127 POPIT modules for
these points.
D8128C
Sensor
Loop
ZONEX 1
D9412
Point
D8128C
Switches
01234
ZONEX 2
D9412
Point
D8128C
Sensor
Loop
ZONEX 1
D9412
Point
D8128C
Switches
01234
ZONEX 2
D9412
Point
P1 009 129 P1 073 193
P2 010 130 P2 074 194
P3 011 131 P3 075 195
P4 012 On On On On -- 132 P4 076 Off On On On -- 196
P5 013 133 P5 077 197
P6 014 134 P6 078 198
P7 015 135 P7 079 199
P8 016 136 P8 080 200
P1 017 137 P1 081 201
P2 018 138 P2 082 202
P3 019 139 P3 083 203
P4 020 OnOnOnOff-- 140 P4 084 OffOnOnOff-- 204
P5 021 141 P5 085 205
P6 022 142 P6 086 206
P7 023 143 P7 087 207
P8 024 144 P8 088 208
P1 025 145 P1 089 209
P2 026 146 P2 090 210
P3 027 147 P3 091 211
P4 028 On On Off On -- 148 P4 092 Off On Off On -- 212
P5 029 149 P5 093 213
P6 030 150 P6 094 214
P7 031 151 P7 095 215
P8 032 152 P8 096 216
P1 033 153 P1 097 217
P2 034 154 P2 098 218
P3 035 155 P3 099 219
P4 036 On On Off Off -- 156 P4 100 Off On Off Off -- 220
P5 037 157 P5 101 221
P6 038 158 P6 102 222
P7 039 159 P7 103 223
P8 040 160 P8 104 224
P1 041 161 P1 105 225
P2 042 162 P2 106 226
P3 043 163 P3 107 227
P4 044 On Off On On -- 164 P4 108 Off Off On On -- 228
P5 045 165 P5 109 229
P6 046 166 P6 110 230
P7 047 167 P7 111 231
P8 048 168 P8 112 232
P1 049 169 P1 113 233
P2 050 170 P2 114 234
P3 051 171 P3 115 235
P4 052 On Off On Off -- 172 P4 116 Off Off On Off -- 236
P5 053 173 P5 117 237
P6 054 174 P6 118 238
P7 055 175 P7 119 239
P8 056 176 P8 120 240
P1 057 177 P1 121 241
P2 058 178 P2 122 242
P3 059 179 P3 123 Do not use 243
P4 060 On Off Off On -- 180 P4 124 D8128C module 244
P5 061 181
P5 125
for these points
245
P6 062 182 P6 126 246
P7 063 183 P7 127 247
P8 064 184 P8 128
Reserved for internal use
248
P1 065 185
P2 066 186
P3 067 187
P4 068 On Off Off Off -- 188
P5 069 189
P6 070 190
P7 071 191
P8 072 192
