D9000/D7000 Series Operation & Installation Manual
Page 66
74-07692-000-C 4/97
Appendix: Point Address Chart
ZONEX 1, Points 9 to 127 (D9412/D9112)
ZONEX 1, Points 9 to 75 (D7412/D7212)
Place the labels on the base of the POPIT. Do not attach label to the POPIT cover.
A number in the switch column indicates that switch is set to ON.
Switch Switch Switch
Address
0123456
Address
0123456
Address
0123456
009 0123456 049 0 2 456 089 1 3456
010 012345 050 0 2 45 090 1 345
011 01234 6 051 0 2 4 6 091 1 34 6
012 01234 052 0 2 4 092 1 34
013 0 1 2 3 5 6 053 0 2 5 6 093 1 3 5 6
014 0 1 2 3 5 054 0 2 5 094 1 3 5
015 0 1 2 3 6 055 0 2 6 095 1 3 6
016 0 1 2 3 056 0 2 096 1 3
017 0 1 2 4 5 6 057 0 3 4 5 6 097 1 4 5 6
018 0 1 2 4 5 058 0 3 4 5 098 1 4 5
019 0 1 2 4 6 059 0 3 4 6 099 1 4 6
020 0 1 2 4 060 0 3 4 100 1 4
021 0 1 2 5 6 061 0 3 5 6 101 1 5 6
022 0 1 2 5 062 0 3 5 102 1 5
023 0 1 2 6 063 0 3 6 103 1 6
024 0 1 2 064 0 3 104 1
025 01 3456 065 0 456 105 23456
026 01 345 066 0 45 106 2345
027 0 1 3 4 6 067 0 4 6 107 2 3 4 6
028 0 1 3 4 068 0 4 108 2 3 4
029 0 1 3 5 6 069 0 5 6 109 2 3 5 6
030 0 1 3 5 070 0 5 110 2 3 5
031 0 1 3 6 071 0 6 111 2 3 6
032 0 1 3 072 0 112 2 3
033 0 1 4 5 6 073 1 2 3 4 5 6 113 2 4 5 6
034 0 1 4 5 074 1 2 3 4 5 114 2 4 5
035 0 1 4 6 075 1 2 3 4 6 115 2 4 6
036 0 1 4 076 1 2 3 4 116 2 4
037 0 1 5 6 077 1 2 3 5 6 117 2 5 6
038 0 1 5 078 1 2 3 5 118 2 5
039 0 1 6 079 1 2 3 6 119 2 6
040 0 1 080 1 2 3 120 2
041 0 2 3 4 5 6 081 1 2 4 5 6 121 3 4 5 6
042 0 2 3 4 5 082 1 2 4 5 122 3 4 5
043 0 2 3 4 6 083 1 2 4 6 123 3 4 6
044 0 2 3 4 084 1 2 4 124 3 4
045 0 2 3 5 6 085 1 2 5 6 125 3 5 6
046 0 2 3 5 086 1 2 5 126 3 5
047 0 2 3 6 087 1 2 6 127 3 6
048 0 2 3 088 1 2 128*
•
* The panel reserves point 128 for internal use.
•
D8127 or D9127 POPITs may be used for points 9-72; however, only D9127 POPITs may be used for points 73-127.
•
D8127 POPITs have dipswitches 1-6
whereas D9127 POPITs have dipswitches 0-6.
