Radionics D7412 User Manual

D9000/D7000 Series Operation & Installation Manual
Page 43
74-07692-000-C 4/97
D9412 FACEPLATE
5
9
10
1
4
2
Low Batter y
LEDs Off When Normal
EARTH GROUND
COMMON
CLASS 2 TRANSFORMER
16.5 VAC 40 VA 60 HZ
Part No. D1640
Internally Fused - Do N ot Short
Requires Unswitched Outlet
Do N ot Share With Other Equipment
+ AUX POWER
BATTERY NEGATIVE ONLY
Maximum Char
g
in
g
Current 1.4 Amps.
PHONE MONITOR SELECT
Loop Start
Ground Start
TELCO
CORD
PHONE
LED
ON W HEN
C O M M U N IC AT IN G
OFF WHEN IDLE
Requires
Relay
#D136
IN J5
ON-BOARD POINTS
1.0K Resistor
Required at End of Line
Ω
VOLTAGE RANGES
Open 3.7 - 5.0VDC
Normal 2.0 - 3.0VDC
Short 0.0 - 1.3VDC
PERIPHERAL DEVICE WIRING
ZONEX OUT 1
ZONEX IN 1
ZONEX OUT 2
ZONEX IN 2
ZONEX POWER +
ZONEX COMMON
Operation Monitor
Pulses When Normal
Flickers W hen Rin
g
in
g
PROG
CONN
RED
YELLOW
GREEN
BL AC K
17-05823-002
32
POWER +
DATA BUS A
COMM ON
RED
GROUND
START
YEL
RED
Reset Pin
Disable All Except Batter
y
Char
g
in
g
And Pro
g
rammin
g
GRN
STEADY OR
PULSE
+
Charging Status
N.F.P.A.
Style 3.5
Signaling
Line
Ci rcui ts
,
12 15
18
21
13
11
14 16 17 19 20 22
PROGRAMMABLE
ALARM OUTPUT S
T er minals
&
Requires
Optional
D136 Relay
in J1 & J9
7 8
Point 1 Point 2 Point 3 Point 4 Point 5 Point 6 Point 7 Point 8
J2
FACEPLATE SHIELD
HOOKS
CHARGING STATUS LED
(Yellow)
COLOR CODED
BATTERY LEADS
PHONE LINE
MONITOR SELECT
JUMPER
TELEPHONE CORD
CONNECTOR
GROUND START RELAY
J5
FACEPLATE SHIELD
STANDOFFS
ACCESSOR Y
CONNECTOR
J2
OPERATION
MONITOR LED
RESET PIN
M
PROGRAMMER
CONNECTOR
J7
DATA BUS B
29
31
30
24
23
28
27
26
25
BATTERY PO SITIVE ON LY
+ ALTERNATE
SWITCHED
AUX POWER
+
3
6
7
8
-
+
LOW BATTERY LED
(Red)
D9412
Di
g
ital Alarm, Communicator Transmitter
