D9000/D7000 Series Operation & Installation Manual
Page 9
74-07692-000-C 4/97
EMI/Lightning Transient Protection
The D9000/D7000 Series Control/
Communicators maintain the Radionics high
level of quality and field dependability. Their
design significantly reduces electromagnetic
interference and malfunction generally caused by
lightning.
Programming
Use either the Radionics D5200 Programmer or
the Remote Account Manager (RAM III) to
program the D9000/D7000 Series Control/
Communicators. Refer to the
D9000/D7000
Series Program Entry Guide
(74-07695-000)
for
programming options.
Other Features
The D9000/D7000 Series Control/Communicator
have many programmable features. A short list of
some of the features follows. Complete details on
all the features can be found in the
D9000/D7000
Series Program Entry Guide
(74-07695-000)
.
• Supervision of AC (primary power), battery
(secondary power), ZONEX and SDI buses,
CPU (Central Processing Unit), up to 3
printers, and telephone lines
• Automatic system test reports
• Remote access for programming, diagnostics,
and log uploads using the Remote Account
Manager (RAM III)
• Fire Alarm Verification
• Programmable Alarm Output
• Programmable Relay Output using the D8129
OctoRelay Module
• Opening and Closing Windows
• Skeds (scheduled events)
Control/Communicator Assembly
The Radionics Control/Communicator is shipped
pre-assembled from the factory. You should
receive the following parts with your panel.
Literature Pack
•
D9000/D7000 Installation and
Troubleshooting Quick Reference
(33317)
•
D9412/D9112 Program Record Sheet
(74-
07697-000), or
D7412/D7212 Program
Record Sheet
(34583)
•
UL Smoke Detector Compatibility
Technogram
(33284)
•
Point Chart Label
(79-06660-000)
• Eight D105BL 1k W end-of-line resistors
• Two 14", 18 AWG, color-coded battery leads
Assembly:
• PC board
• Faceplate shield
• Mounting Skirt
• One #6x1/4" screw
Ordered Separately
Order the following to complete a basic 8 point
installation.
• D1255 or D720 Command Center (or
keyswitch)
• D1640 Transformer
• D126 Battery
• D161 or D162 Phone Cord (order two cords if
you are using the D928 Dual Phone Switcher)
• D8103, D8108A, or D8109 Enclosure
Configured packages are also available. Please
consult your Radionics Product Catalog.
The following literature is available in a separate
literature package for dealers.
• D9000/D7000 Series Operation and
Installation Manual (74-07692-000)
• D9000/D7000 Series Approved Applications
Compliance Guide (74-07693-000)
• D9000/D7000 Series Program Entry Guide
(74-07695-000)
• D9412/D9112 Program Record Sheet (74-
07697-000), and D7412/D7212 Program
Record Sheet (34583)
