D9000/D7000 Series Operation & Installation Manual
Page 61
74-07692-000-C 4/97
Current Rating Chart for Standby Battery Calculations
ABC
AC Power On
Normal Current
AC Power Off
Minimum Current
In Alarm
Maximum Current
Model
Number
Quantity
Used
Each
Unit
*
Total
Each
Unit Total
Each
Unit Total
D9412/D9112/
D7412/D7212
______ 350 x 1 = 350 350 x 1 = 350 500 x 1 = 500
D125B ______ 20 x
Quant.
= ____ 19 x
Quant.
= ____ 123 x
Quant.
= ____
D127 ______ 13 x
Quant.
= ____ 12 x
Quant.
= ____ 45 x
Quant.
= ____
D129 ______ 25 x
Quant.
= ____ 25 x
Quant.
= ____ 25 x
Quant.
= ____
D185 ______ 120 x
Quant.
= ____ 120 x
Quant.
= ____ 350 x
Quant.
= ____
D192D ______ 15 x
Quant.
= ____ 26 x
Quant.
= ____ 50 x
Quant.
= ____
D192C ______ 15 x
Quant.
= ____ 26 x
Quant.
= ____ 50 x
Quant.
= ____
D1255 ______ 104 x
Quant.
= ____ 106 x
Quant.
= ____ 206 x
Quant.
= ____
D1256 ______ 104 x
Quant.
= ____ 106 x
Quant.
= ____ 206 x
Quant.
= ____
D1257 ______ 104 x
Quant.
= ____ 106 x
Quant.
= ____ 206 x
Quant.
= ____
D720 ______ 55 x
Quant.
= ____ 20 x
Quant.
= ____ 75 x
Quant.
= ____
D8125 ______ 48 x
Quant.
= ____ 48 x
Quant.
= ____ 48 x
Quant.
= ____
D8127T/U ______ 3 x
Quant.
= ____ 3 x
Quant.
= ____ 4 x
Quant.
= ____
D8128C ______ 50 x
Quant.
= ____ 50 x
Quant.
= ____ 50 x
Quant.
= ____
D8129 ______ 20 x
Quant.
= ____ 20 x
Quant.
= ____ 20 x
Quant.
+ (25 x
# of relays
) = ___
D8130 ______ 5 x
Quant.
= ____ 5 x
Quant.
= ____ 54 x
Quant.
= ____
D9127T/U ______ 0.5 x
Quant.
= ____ 0.5 x
Quant.
= ____ 0.8 x
Quant.
= ____
D9131A ______ 24 x
Quant.
= ____ 22 x
Quant.
= ____ 36 x
Quant.
= ____
D9210B ______ 100 x
Quant.
= ____ 100 x
Quant.
= ____ 120 x
Quant.
= ____
D928 ______ 14 x
Quant.
= ____ 14 x
Quant.
= ____ 45 x
Quant.
= ____
Ratings of other devices in the system which are not shown above:
________ ______ ____ x
Quant.
= ____ ____ x
Quant.
= ____ ____ x
Quant.
= ____
________ ______ ____ x
Quant.
= ____ ____ x
Quant.
= ____ ____ x
Quant.
= ____
________ ______ ____ x
Quant.
= ____ ____ x
Quant.
= ____ ____ x
Quant.
= ____
________ ______ ____ x
Quant.
= ____ ____ x
Quant.
= ____ ____ x
Quant.
= ____
________ ______ ____ x
Quant.
= ____ ____ x
Quant.
= ____ ____ x
Quant.
= ____
Total A = _____ Total B = _____ Total C
**
= _____
NOTES:
* Currents shown in milliamperes (1 ampere = 1000 milliamperes)
** If the column C total exceeds 1400 mA, a D8132 is required to provide an additional 1400 mA. You may
also use a UL listed external power supply for this purpose.
