Radionics D7412 User Manual

D9000/D7000 Series Operation & Installation Manual
Page 53
74-07692-000-C 4/97
5. During the Service Walk Test you may want
to see the points that remain untested. When
point text is displayed, press "ESC". The
display shows ## PTS TO TEST . Press the
"ESC" key. VIEW UNTESTED ? is
displayed. Press ENT. ## PTS UNTESTED is
displayed. Press NEXT to see a list of the
points that have not yet been tested. Move
through this list by pressing the NEXT key.
To resume the Service Walk Test, press
"ESC". ## PTS UNTESTED is displayed.
Press "ESC". ## PTS TO TEST is displayed.
Resume testing points. To end the Service
Walk Test, press "ESC" twice.
6. After testing the last point, 0 PTS TO TEST
displays. Press "ESC". The display
momentarily shows ALL PTS TESTED
before returning to idle text.
Note: The Service Walk Test, when performed on
a D7412 or D7212, cannot display “0 points to
test” as it is physically unable to connect to the
second POPEX module (used for points 129-
247).
Automatic time-out returns the system to idle
text: If there is no point or Command Center
activity for 20 minutes, the walk test ends
automatically. The Command Center returns to
idle text.
Figure 21: Service Walk Test Flow Chart
ENT
VIEW UNTESTED ?
ENT
# PTS UNTESTED
NEXT
SERVICE WALK ?
246 PTS TO TEST
245 PTS TO TEST
244 PTS TO TEST
POINT TEXT
POINT TEXT
POINT TEXT
1 PTS TO TEST
0 PTS TO TEST
POINT TEXT
Test a device
(Text displays 60 seconds)
Test a device
(Text displays 60 seconds)
Test a device
Test a device
IDLE TEXT
ESC
ESC
ESC
ESC
