18.2. WIFI port settings
CAUTION:
1. The transmission parameters must be matched to the client’s local
network.
2. Most Wi-Fi modules work on one channel, which is defined in the
configuration of the Wi-Fi network.
3. To ensure proper operation of the Wi-Fi router, automatically
changing channels when configuring the connection set
<AUTOCHANNEL> to <YES>.
The parameters available for the Wi-Fi connection settings:
P3.3.1 – STATUS
P3.3.2 – CHOOSE NETWORK
P3.3.3 – NETWORK SETTING
P3.3.3.1 – NAME (the name of the network that has been selected)
P3.3.3.2 – PASSWORD (password – ‘stars’ are displayed)
P3.3.3.3 – CHANNEL NO (default <AUTO>)
P3.3.3.4 – IP (balance ID number, make sure that the number is not
engaged by a different device operating in this network)
P3.3.3.5 – MASK (default 255.255.000.000)
P3.3.3.6 – GATE (default 10.10.8.244)
P3.3.3.7 – PORT (default 4000)
P3.3.3.8 – MAC ADRES (0008DC…)
P3.3.4 – WIFI STARTUP
After entering the parameter, the message <STATUS> and the value describing the
state of the network Wi-Fi appear in the bottom line.
• CONNECT – it means that the balance is connected to one of the
available Wi-Fi networks, additionally, at the top of the display the
pictogram
appears. It is visible when the balance has an
active network connection.
• CONNECTIVITY – it means that the balance is trying to connect to the
network, to which it was previously connected, for previously
entered settings (network, IP, etc.)
• NONE – the module Wi-Fi is not installed in the balance.
