Radware Alteon Installation and Maintenance Guide
Specifications
80 Document ID: RDWR-ALOS-V2815_IG0203
SSL CPS
(Connections per
Second)
500 CPS scalable up to 2,000 CPS 10,000 CPS scalable up to 32,000 CPS
Compression 500 Mbps scalable up to 3.6 Gbps
Routing protocols BGP, OSPF, RIP, RIP 2—as applicable
Processor Intel quad-core
Hard disk Yes
RAM 6 GB up to 24 GB 12 GB up to 24 GB
CompactFlash 1 GB
Physical ports—
general
Eight (8) Gigabit Ethernet ports
Sixteen (16) Gigabit Ethernet fiber ports (SFP-GBIC Mini)
Two (2) 10 Gigabit Ethernet fiber ports (XFP-GBIC)
Note: For additional details, see Alteon Application Switch Platforms, page 27
and Transceiver Module Specifications for Alteon Application Switch
Platforms, page 84.
1000BASE-SX/
LX/ZX ports
All relevant, fiber ports support SX/LX/ZX interfaces depending on the
transceiver module.
1000Base-SX
(850 nm)
Operating
Distance
62.5 micron MM fiber .2 m to 275 m
50 micron MM fiber .2 m to 550 m
1000Base-LX/ZX
Operating
Distance
LX: Up to 10 km (6.2 mi)
ZX: Up to 80 km (49.7 mi)
USB port On front panel
LCD screen None
RS-232 console RJ-45 Serial Connection
Dimensions 2U:
• Width: 424 mm (17 in.)
• Depth: 426 mm (17 in.)
• Height: 88 mm (3.4 in.)
EIA rack or stand-alone: 484 mm (19 in.)
Weight Single Power Supply 9.3 Kg (20.5 lbs)
Dual Power Supply 10.8 Kg (23.8 lbs)
Single Power Supply 9.8 Kg (21.6 lbs)
Dual Power Supply 11.3 Kg (24.9 lbs)
Environmental Operating temperature: 0ºC to 40ºC (32ºF to 104ºF)
Humidity: 10% to 95% non-condensing
Auto-range
supply
AC:
• 100V–240V
• Frequency: 47Hz–63Hz
DC: –36V~–72V
Dual power supply (AC/DC) is optional
Table 15: General Specifications of Alteon Application Switch 5224 and 5224 XL Platforms
Item Alteon Application Switch 5224 Alteon Application Switch 5224 XL
