Radware Alteon Installation and Maintenance Guide
Specifications
82 Document ID: RDWR-ALOS-V2815_IG0203
DC Power Supply Connectors for Alteon Application Switches
Use the 12-gauge insulated copper DC-input cables for the connection to each DC power supply. This
section contains the following topics:
• DC Power Supply Connector for Alteon Application Switch 4408 Single and Dual Power Supply,
4416 Single Power Supply, and 5224 Single and Dual Power Supply
1000Base-SX
(850 nm)
Operating
Distance
62.5 micron MM fiber .2 m to 275 m
50 micron MM fiber .2 m to 550 m
1000Base-LX/ZX
Operating
Distance
LX: Up to 10 km (6.2 mi)
ZX: Up to 80 km (49.7 mi)
USB port On front panel
LCD screen On front panel
RS-232 console DE-9 serial connection
Female DCE interface for out-of-band management
Dimensions 2U:
• Width: 424 mm (17 in.)
• Depth: 600 mm (24 in.)
• Height: 88 mm (3.4 in.)
EIA rack or stand-alone: 484 mm (19 in.)
Weight 15.44 kg (34 lbs) 15.94 kg (35.1 lbs)
Environmental Operating temperature: 0ºC to 40ºC (32ºF to 104ºF)
Humidity: 5% to 95% non-condensing
Auto-range
supply
AC:
• 100V–240V
• Frequency: 47Hz–63Hz
DC: –36V~–72V
Dual power supply (AC/DC) for relevant models is included.
Power
consumption
488 W 510 W
Heat dissipation 1664 BTU/h 1739 BTU/h
Certifications Safety: CB, cTUVus, IEC #60950-1
EMC: CE - EN 55022, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC Part 15B
Class A, IEC 61000 4-2 to 4-6, IEC 61000 4-8 and IEC 61000-4-11, ICES-003,
VCCI Class A, KCC
RoHS 6 Compliant
CPU temperature SNMP traps are sent in response to high temperatures:
Warning: 69º C
Critical: 74º C
Table 16: General Specifications of Alteon Application Switch 5412 and 5412 XL Platforms
Item Alteon Application Switch 5412 Alteon Application Switch 5412 XL
