Document ID: RDWR_APSV_V400_IG1808 73
APPENDIX A – SPECIFICATIONS
This appendix contains specifications for all Radware platforms and includes the following sections:
• APSolute Vision ODS-VL Platform Specifications, page 73
• APSolute Vision ODS-VL2 Platform Specifications, page 74
• Airflow Requirements, page 75
• AC Power Factor, page 75
• Serial Cable Pin Assignment, page 76
APSolute Vision ODS-VL Platform Specifications
Table 5: General Specifications of APSolute Vision ODS-VL Physical Platform
Item OnDemand Switch VL
Processor Intel Q9400 quad-core 2.66 GHz
Hard disk Yes
RAM 8 GB
CompactFlash 1 GB
Physical ports—general Two 8P8C Gigabit Ethernet ports
USB port Yes
LCD screen No
RS-232 console Via RJ-45. Radware supplies a RJ–45 to DB–9 adapter cable to connect
the console port of the platform to a console PC.
Dimensions Width: 424 mm (17 in.)
Depth: 457 mm (18 in.)
Height: 44 mm (1.7 in.)
EIA rack or stand-alone: 483 mm (19 in.)
Weight 7.6 kg (16.8 lbs.)
Environmental Operating temperature: 0 ºC to 40 ºC (32 ºF to 104 ºF)
Humidity: 10% to 90% non-condensing
Auto-range supply AC:
• 100V–240V
• Frequency: 47Hz–63Hz
DC: –36V~–72V
Power consumption 184 W
Heat dissipation 627 BTU/h
CPU temperature SNMP traps are sent in response to high temperatures:
• Warning: 74 ºC
• Critical: 81 ºC
Note: When the platform reaches the critical temperature, it will
automatically shut down.
