8.5 Certified Antennas
Only the antennas shown in the tables below or antennas of the same type with lower gain
are approved for use in this system. The antennas must be installed so as to provide a
minimum separation distance from bystanders as specified in the tables below.
8.5.1 For Deployment in US and Canada
Radio devices labeled FCC ID: Q3KRW24MOD / IC: 5100A‐RW24MOD
Only the antennas shown in the table below or antennas of the same type with lower gain
are approved for use in this system. The antennas must be installed so as to provide a
minimum separation distance from bystanders as specified in the following table:
Cat. No.
Type
Gain
(dBi)
Dir
BW
Freq. Band
(MHz)
Tx Power per chain
(dBm)
Min. Safe
Distance
(cm)
Integrated
Omni
8
360°
2400‐2483.5
25
20
RW‐9612‐
2427
Flat
DP
20
16°
2400‐2483.5
22
51
Integrated
Flat
DP
17.5
16°
2400‐2483.5
23
43
Radio devices labeled FCC ID: Q3K‐ 5XACMOLD / IC: 5100A‐ 5XACMOD
Only the antennas shown in the table below or antennas of the same type with lower gain
are approved for use in this system. The antennas must be installed so as to provide a
minimum separation distance from bystanders as specified in the following tables:
Frequency Band 5725‐5850 MHz
Cat. No.
Type
Gain (dBi)
Dir
BW
Tx Power per chain (dBm)
Min. Safe Distance
(cm)
Integrated
Flat DP
16.0
35°
25
45
Integrated
Flat DP
16.5
35°
25
48
RW‐9613‐4960
Flat DP
23.0
8°
25
100
Integrated
Flat DP
23.5
8°
25
107
RW‐9622‐5001
Flat DP
29.0
5°
25
200
