Radwin RW 2000 Series User Manual

Page 88
June 2023
Corporate Headquarters | T. +972.3.766.2900 | E. sales@radwin.com | www.radwin.com
Figure 52 Swivel vertically (LFF ODU shown)
3. Once alignment is complete, tighten the bolt holding the ODU on the mounting kit.
Figure 53 Tighten bolt (LFF shown)
• The subscriber ODU will stop beeping when it is aligned with the base station
and configured.
• You can use the RSS indicator on the main window of the RADWIN Manager for
a more accurate indication of the signal strength.
• You can manually cease the beeping via the RADWIN Manager application.
7.2 Aligning RADWIN 2000 Alpha EMB and RADWIN
2000 Alpha INT ODUs
Align the RADWIN 2000 Alpha EMB and RADWIN 2000 Alpha INT ODUs as described in
the following sections:
