SERVICING AND MAINTENANCE 395
F03 – 5 Amp Tan MGU
F04 – – Spare
F05 – – Spare
F06 – 10 Amp Red Spare
F07 – – Spare
F08 20 Amp Blue – Trailer Tow Backup
F09 – 20 Amp Yellow Trailer Stop / Turn Lamp Left
F10 – 20 Amp Yellow Trailer Stop / Turn Lamp Right
F11 – 15 Amp Blue ID/CLEARANCE LIGHTS *
F12 20 Amp Blue – Trailer Tow Park Lamp
F13 – – Spare
F14 – 10 Amp Red AC Clutch
F15 – 5 Amp Tan Intelligent Battery Sensor (IBS)
F16 – – ADCM *
F17 – 20 Amp Yellow Air Suspension
F18 – 15 Amp Blue AGS / Rear Axle Cooling Valve / Active Air Dam
F19 – – Spare
F20 – 20 Amp Yellow Adjustable Pedals
F21 30 Amp Pink – Power Side Step
F22 50 Amp Red – Air Module
Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
8
To Next Page
