396 SERVICING AND MAINTENANCE
F23 – – Spare
F24 – 20 Amp Yellow TCM SBW
F25 40 Amp Green – MOD CBC 4 Exterior Lights 2
F26 50 Amp Red – ESP Module
F27 30 Amp Pink – Front Wiper
F28 – 10 Amp Red PCM / ECM
F29 40 Amp Green – ESP Module
F30 – – Spare
F31 – – Spare
F32 20 Amp Blue – ECM / PCM
F33 30 Amp Pink – Brake Vacuum Pump
F34 – – Spare
F35 – 10 Amp Red
PCM / ECM / Power Pack Unit (PPU) Motor Generator Unit
(MGU
) Wake Up / EPS / Active Tuned Mass Module (ATMM) /
ESP
F36 – – Spare
F37 – 5 Amp Tan R / S Output to iPDC
F38 – 10 Amp Red DTCM / Active CL TEMP VLV
F39 – 15 Amp Blue MOD ATMM
F40 40 Amp Green – Starter
F41 – 10 Amp Red IRCAM Heaters
Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
