SERVICING AND MAINTENANCE 397
F42 20 Amp Blue – AUX SWITCH #5 *
F43 – 20 Amp Yellow MGU Coolant Pump
F44 – 10 Amp Red Trailer Camera
F45 – 10 Amp Red ADCM *
F46 30 Amp Pink – Fuel Heater
F47 30 Amp Pink – Rear Defroster
F48 – – Spare
F49 30 Amp Pink – Htr Ctrl (Diesel Only)
F50 20 Amp Blue – AUX SWITCH #6 *
F51 25 Amp White – FUEL PUMP MOTOR #1 *
F52 – – Spare
F53 – 10 Amp Red Supply / Purging Pump *
F54 – 15 Amp Blue PCM
F55 – 15 Amp Blue Right HID Headlamp
F56 – – Spare
F57 – 20 Amp Yellow Horn
F58 25 Amp White – FUEL PUMP MOTOR #2 *
F59 – 25 Amp Clear Injectors / IGN Coil / Glow Plug Module
F60 – 20 Amp Yellow ECM / PCM / ACT Short Running Valve
F61 – 15 Amp Blue Left HID Headlamp / Spare
Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
