Cavity Cartridge Fuse Micro Fuse Description
F01 30 Amp Pink – Trailer Tow Receptacle
F03 – 20 Amp Yellow Module Seat Heater Front (Pass)
F04 – – Spare
F05 – 20 Amp Yellow Module PPU Cooling Fan
F06 – – Spare
F07 40 Amp Green – Mod CBC 3 PWR Locks
F08 – – Spare
F09 – – Spare
F10 40 Amp Green – HVAC Blower Motor
F11 – 5 Amp Tan
Output to Under-hood Power Distribution Center (UPDC) Run
Coil
F1
2 – 25 Amp Clear Mod Audio Amplifier / Active Noise Cancellation / SW Inverter
F13 – 20 Amp Yellow Mod Seat Heater Front (Driver)
F14 – 15 Amp Blue Mod Seat Heater Front (Steering Wheel)
F15 – – Spare
F16 – – Spare
F17 – 20 Amp Yellow LT Spot Lamp
F18 30 Amp Pink – Motor Sunshade Sunroof
F19 – – Spare
F20 – 20 Amp Yellow Comfort Rear Seat Module (CRSM) (Heat Rear RT)
F21 – – Spare
F22 – – Spare
F23 – – Spare
8
