R&S TSMA6 Getting Started

Preparing for Use
R&S
®
TSMA6
11Getting Started 4900.8040.02 ─ 07
Accessories
The following items are included with shipment of the R&S TSMA6:
●
12 V DC power supply cable with a cigarette lighter connector
●
Wide range RF paddle antenna (700 MHz to 2600 MHz)
●
Active GPS patch antenna
●
LAN cable with ferrit
●
Ferrit for LAN cable supplied by the customer
Optional Accessories
The following items are optionally available.
●
TSMA6-ZCB2 (Carrying Bag)
●
TSMA6-Z1 (AC Adapter)
●
TSMA6-Z2 (19" Rack Adapter)
●
TSMA6-Z5 (Carrying Box)
4.2 Connecting External Devices
The following external devices must be connected before connecting the power
supply.
The SMA connector is sensitive to mechanical stress. Use the following
handling precautions.
●
Always use a torque wrench and mount the cable end with 60 Ncm.
●
Do not stack adapters directly at the SMA connector. If you need to use
adapters (e.g: SMA to N), then always use a specific adapter cable
(R&S no. 4900.1700.00).
To select the correct connectors, refer to Chapter 5.2, "Rear Panel View",
on page 22.
1. Connect the RF antenna to the RF IN connector (see Figure 5-2 - 14).
2. Connect the GPS antenna to the GPS ANT port (see Figure 5-2 - 4).
Connecting External Devices
