Preparing for Use
R&S
®
TSMA6
17Getting Started 4900.8040.02 ─ 07
1 = Move R&S TSMA6 vertically
2 = Move R&S TSMA6 horizontally
3 = Power Connection established
The power-up behavior after connecting the R&S TSMA6-BP Battery Pack
Unit (including charged batteries or connected to an external DC power sup-
ply) with the R&S TSMA6 depends on the system settings on the
R&S TSMA6.
● Auto Power On
The R&S TSMA6 starts automatically when power is applied at the DC IN
connector of the R&S TSMA6 or at the DC IN connector of a connected
R&S TSMA6 Battery Pack.
● Remember Last State
The R&S TSMA6 remembers the last state before the DC power was
removed
● Startup Delay
"Auto Power On" after a configurable time delay
● Auto Power Off
"Auto Power Off" after a configurable time delay if the R&S TSMA6 is con-
nected to a R&S TSMA6 Battery Pack.
4.4 Switching On R&S TSMA6
To switch on the device, press the POWER ON/OFF button.
Switching On R&S TSMA6
