Preparing for Use

R&S

TSMA6

16Getting Started 4900.8040.02 ─ 07

Figure 4-5: R&S

TSMA6

1* = Power connector for R&S TSMA6-BP

*On delivery the power connector is protected by a cover cap.

4. Set the R&S TSMA6 vertically on top of the R&S TSMA6-BP (1).

5. Slide the R&S TSMA6 horizontally (2) until it engages in the mechanical con-

nectors on top of the R&S TSMA6-BP. (Noticeable by a "click" sound.)

Figure 4-6: Connected R&S

TSMA6 and R&S

TSMA6-BP

Connecting Power Supply
