Preparing for Use
R&S
®
TSMA6
15Getting Started 4900.8040.02 ─ 07
3. Attach the R&S TSMA6 with the bottom side (see Figure 4-5) on top of the
R&S TSMA6-BP (see Figure 4-4).
Figure 4-4: R&S TSMA6-BP
1 = Mechanical connectors for R&S TSMA6
2 = Power connector for R&S TSMA6
Connecting Power Supply
