5 Instrument Tour

5.1 Front Panel View

The front panel of the R&S TSMA6 does not provide any connectors or control

elements for operation.

Figure 5-1: R&S

TSMA6 - Front Panel

5.2 Rear Panel View

The following figure provides an overview of the control elements and the connec-

tors on the rear panel of the instrument.

Figure 5-2: R&S

TSMA6 - Rear Panel

1 = WLAN/Bluetooth ON/OFF

2 = SCAN Port - Gbit LAN IF- 2nd Scanner (TSME4/6)

3 = AUX Connector (SMA) - Synchronization

4 = GPS Ant. Connector (SMA) - GPS antenna input

5 = Scanner Pwr / State, Mode, Meas - Status LEDs

6 = POWER ON/OFF

Rear Panel View
