R&S TSMA6 - Connecting an AC Power Supply

Preparing for Use
R&S
®
TSMA6
13Getting Started 4900.8040.02 ─ 07
Figure 4-1: Supplied power cable with cigarette lighter adapter
4.3.2 Connecting an AC Power Supply
To operate the R&S TSMA6 with an AC power supply, connect the DC IN connec-
tor with the AC power supply (R&S TSMA6-Z1, R&S No. 4901.0550.02).
Connecting Power Supply
