Preparing for Use

R&S

TSMA6

12Getting Started 4900.8040.02 ─ 07

3. Connect mouse and keyboard to the USB 2.0 ports (see Figure 5-2 - 11) and

a monitor to the appropriate monitor port (HDMI, USB-C)) (see Figure 5-2 -

13, 9) if you want to use local operation. (optional)

4. Connect a LAN cable to the LAN port if you want to use the R&S TSMA6 via

Remote Desktop or as distributed system (optional). (See Figure 5-2 - 12.)

5. OPTIONAL: Connect external devices/storage devices and test mobile

phones to USB 2.0 / USB 3.0 / USB-C ports (see Figure 5-2 - 9, 10, 11).

4.3 Connecting Power Supply

This section describes how to connect the R&S TSMA6 to a power supply unit.

4.3.1 Connecting to a Vehicle DC Power Supply

For 12V Vehicle DC Supply Only

The R&S TSMA6 is to be used with a 12 V vehicle power supply only.

Use the accessory DC cable with cigarette lighter adapter to power the

R&S TSMA6 from the vehicle power supply. Connect the 7-pin connector to DC

IN.

Connecting a proprietary power supply

► To use a proprietary DC supply with the R&S TSMA6 power cable, demount

the cigarette lighter adapter from the supplied power cable and connect the

open ends of the cable to the proprietary power supply. Be sure to respect the

correct polarity (see Figure 4-1).

Connecting Power Supply

R&S TSMA6 Getting Started
