Instrument Tour

R&S

TSMA6

24Getting Started 4900.8040.02 ─ 07

The R&S TSMA6 can perform dead reckoning in tunnels to provide position infor-

mation even if no satellites are available. The dead reckoning is performed in the

device itself by built-in electronic gyroscopes.

For enabling untethered dead reckoning, see Chapter 4.8, "Enabling Untethered

Dead Reckoning ", on page 21.

Depending on the intended use, the respective valid regulations regarding

lightning protection of the antennas and regarding vehicle installation must

be observed during installation.

Status LEDs

The four status LEDs, [Scanner State], [Scanner Pwr], [Mode], and [Meas] indica-

ted different states of the R&S TSMA6. For a detailed description, see Chap-

ter 5.3, "Status LEDs", on page 26.

Power ON/OFF

The POWER ON/OFF button turns on and off the device.

Press and hold the button results in a coldstart of the R&S TSMA6.

Restore

Press the RESTORE button ( > 20 sec) to bring the system partition of the

embedded Windows CPU back to factory default or to a user backup (if created).

Loss of user data after RESTORE

Executing restore brings the R&S TSMA6 irreversible back to the condition

of delivery or any other later stored backup version.

All user data since last backup is lost.

DC IN Connector

The DC IN connector is used to supply the R&S TSMA6 with DC power. A wide

DC input range 11 V to 18 V / max. 7 A is supported.

Rear Panel View
