Ransomes Commander 3520 - 4 Specification; Engine Specification; Machine Specification

en-8
4 SPECIFICATION
4.1 ENGINE SPECIFICATION_____________________________________________
Type:
Kubota 36.4KW (48.8HP) @ 2800
RPM, 4 cylinder (in line) vertical Diesel
engine, 4 stroke, water cooled, 2197cc
(134.06 cu.in) with 12V electric start.
Model: V2203 -M-E2B-RANUK-1
Maximum Speed: 2800 +0 / -50 RPM (No load)
Idle Speed: 1400 ± 50 RPM
Oil Sump Capacity:
9.5 litres (16.72 Imp.pints) (20.08 US
pints)
Firing Order: 1, 3, 4, 2.
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION ___________________________________________
Frame construction: Heavy duty fabricated steel chassis.
Cutting unit drive: Hydraulic, with forward, neutral, reverse control valve. Floor mounted switch for
cylinder engage. Hand control valve for reel speed adjustment.
Transmission: Hydrostatic power provided by a servo-controlled transmission pump. Driving 4
individual wheel motors with selectable 2 or 4WD.
Speeds:
Cutting: 12 km/h (7 mph)
Transport: 25 kp/h (15 mph)
Reverse: 6 kp/h (4 mph)
Steering: Hydrostatic power steering to rear wheels.
Ground pressure: 1.0 kg/cm (14.5p.s.i)
Brakes, Service: Positive hydostatic braking.
Parking: Fail safe, Oil immersed wet disc brakes.
Capacities:
Cooling System: 6.8 litres (12 Imp. pints) (14.4 US pints)
Fuel Tank: 54 litres (11.9 Imp. galls) (14.3 US galls)
Hydraulic Tank: 52 litres (11.
4 Imp. galls) (13.7 US galls)
Battery: 665
TYRE PRESSURE
Product
Front Wheel Rear Wheel
Tyre Size Tyre Type Tyre Pressure Tyre Size Tyre Type Tyre Pressure
Com-
mander
3520
26 x 12.00 -
12
Titan Multi Trac 6pr 14 -20 psi 1.00 - 1.37
bar
23 x 10.50 -
12
Titan Multi Trac 6pr 14 -20 psi 1.00 - 1.37
bar
Maxxis Turfmaxx
(Kevlar) tread pattern
C-165s 4pr
20 - 22 psi 1.37 - 1.50
bar
Maxxis Turfmaxx
(Kevlar) tread pattern
C-165s 4pr
20 - 22 psi 1.37 - 1.50
bar
