4 SPECIFICATION
4.3 DIMENSIONS _________________________________________________________
4.4 VIBRATION LEVEL__________________________________________________
The machine was tested for whole body and hand/arm vibration levels. The operator was seated in the normal
operating position with both hands on the steering mechanism. The engine was running and the cutting device
was rotating with the machine stationary.
Hand / Arm acceleration level: 0.37 m/s
2
Whole body acceleration level m/s
2
4.5 SLOPES___________________________________________________________
DO NOT USE ON SLOPES GREATER THAN 15° The slope 15° was calculated using static stability measure-
ments according to the requirements of EN 836
4.6 RECOMMENDED LUBRICANTS _______________________________________
Engine oil: Should be to MIL-L-2104C or to A.P.I. Classification CD grades. [10W-30]
Hydraulic Oil: Shell Tellus 46 to ISO VG46, or equivalent.
Grease: Shell Darina R2, or equivalent.
A Width of Cut: 3.50 metres (138in)
B Overall Width: 2.00 metres
C Overall Width Transport (minimum): (78.8in)
D Overall Height 1.45 metres (57in)
E Overall Length: 3.10 metres (123 in)
F Overall weight of machine: 2080kg (4576lbs)*
G Wheel Track: 1.5 metres (59in)
H Wheel Base: 1.65 metres (65in)
J Ground Clearance: 161mm (6 5/16in)*
* With Sport 200 8-knife floating head units.
Floor Location Seat Location
xyzxyz
Mean 0.0152 0.0282 0.0389 0.01 0.0195 0.0315
