7 OPERATION
(d) Retighten air vent.
NOTE: Always keep the air vent tap on the fuel
injector pump closed except when air is being
vented, or it may cause the engine to stop.
(e) Turn ignition to OFF.
ENGINE LUBRICATION OIL__________________________________________________
(a) Fill the engine sump with oil to API
classification CC/CD/CE grade through
the filler (A Fig.7.4.2)
(b) Always check level of oil with the dipstick
(AFig.7.4.5) and ensure machine is on
l evel ground when checking. Capacity 9.5
litres (16.72 Imp pints) (20.08 US pints)
COOLANT
Fill the radiator (A Fig.7.4.3) and half fill the
expansion tank (B Fig.7.4.3) with a 50% antifreeze
solution.
Capacity 6.8 litres (12 imp pints) (14.4 US pints)
IMPORTANT
Always allow the engine to warm up sufficiently
before full load and speed is applied, otherwise
the life of the engine will be shortened.
Fig.7.4.4
Fig.7.4.5
