12 SCHEMATICS
12.5 ELECTRICAL KEY
KEY TO WIRING DIAGRAM
1. Stop Lamp Relay
2. Seat Relay
3. Start Relay 1
4. Start Relay 2
5. Flasher Relay
6. Horn Relay
7. Fuse Block
8. Lamp Timer
9. Cab Supply
10. Master Fuse
11. Key Switch
12. Setup Switch
13. Horn Switch
14. Engage III 10 pin Connector
15. Engage III 8 Pin Connector
16. Indicator Lamp
17. Indicator Switch
18. Lights Switch
19. 4 Wheel Drive Switch
20. Beacon Switch
21. Hazard Switch
22. Access 2
23. Access 1
30. Safety Diode
47. 10 Pin Connector to Main Harness
48. 24 Pin Connector to Main Harness
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
E.G. R/W = Red/White
