3 | Product description
14 / 84 80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
Device size 20 half size and 20 full size GN
The connections for the installation are located on the underside of the device
and run to the rear:
3
4
7
1
2
5
6
1 Water connection 2 Cable bushing for electrical con-
nection
3 Equipotential bonding 4 Waste water connection
5 Safety overflow for wastewater
connection
6 Network connection
7 Only for gas devices: Gas connec-
tion
3.2 Technical data
Protection class
The device corresponds to jet water connection class IPX5.
Ambient conditions
n
Do not set up the device in ambient temperatures below 10 °C [50 °F].
n
Do not commission the device in ambient temperatures below 10 °C [50
°F].
n
Set up the device in rooms with adequate ventilation via windows or an
extractor hood.
Sound emission value
The sound emission value is <65 dB.
