5 | Setup
80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US 29 / 84
5.1.2 Distance from heat sources
NOTE
Minimum distance is not observed
To avoid damage to the device or malfunctions, the device should be set up
with the specified minimum distance from heat sources or open flames.
NOTE
High ambient temperature next to the installation area (left side of the
device)
If the temperatures in the installation area on the left side of the device
exceed 80°C [176°F], the heating system is switched off by an automatic
safety switch-off.
NOTE
High ambient temperatures at the rear of the device
Do not place deep fryers or other heat sources at the rear of the device.
Set up the device with a minimum distance from heat sources on the left.
Minimum distance to heat sources
x [mm] 350
x [inch] 14
Heat shield (optional)
If a sufficient distance to the heat source on the left cannot be maintained, an
additional heat shield is available to reduce the thermal load.
For the device sizes 6 half size GN and 10 half size GN, an additional heat shield
is available for the right side.
