5 | Setup
28 / 84 80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
If this distance to the left side of the device is not possible, place the device so
that it can be pulled out of the niche for maintenance work.
Distance to the left side of the device
x (mm) 500
x (inch) 20
Recommended distance to the right side of the device
To open the device door at the first grid, place the device on the right with a
recommended minimum distance to the wall. The distance depends on the de-
vice size, as shown in the table below.
Device size XS 6 half
size
6 full
size
10 half
size
10 full
size
20 half
size
20 full
size
z (mm) 279 246 316 246 316 268 338
z (inch) 11 10 12 1/2 10 12 1/2 11 13
