6 | Electrical connection
54 / 84 80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
Device size 6 half size GN to 10 full size GN
Device size 20 half size GN, 20 full size GN
6.9 Connected loads of different voltage types
Maximum connection voltage
n
Maximum permissible tolerance for the input voltage: -15% to +10%
n
The device can be used with frequencies of 50Hz and 60Hz without tech-
nical modifications.
iCombi Pro, iCombi Classic Electrical devices
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-2/3 (2 AC 208 V) 60 28 5.7 30/35 B
6-1/1 E (2 AC 208 V) 60 53 10.8 60 B
