5 | Setup
30 / 84 80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
Please note: The heat shield for the device sizes 6 half size GN to 20 full size
GN is not suitable for Combi-Duo and UltraVent.
5.1.3 Distance to ceiling
Electrical devices
Install the electrical device with a minimum distance between the ventilation
pipe of the device and the grease filters of the extraction hood/ventilation
ceiling.
Minimum distance from ceiling
x [mm] 254
x [inch] 10
Gas devices
Install the gas device with a minimum distance between the flue gas pipes of
the device and the grease filters of the extractor hood/ventilation ceiling.
